Vmpp (voltage at maximum power): approx. 41.17 V
Impp (current at maximum power): approx. 15.19 A
Voc (open-circuit voltage): approx. 49.38 V
Isc (short-circuit current): approx. 16.01 A
1
/
of
4
Solar Space 630wp SSA-66HD Silver Frame
Solar Space 630wp SSA-66HD Silver Frame
Regular price
€98,48 EUR
Regular price
Sale price
€98,48 EUR
Unit price
/
per
Shipping calculated at checkout.
6858 in stock
- 100% certified
- Ready for Installation
- Fast delivery within NL & BE
Couldn't load pickup availability
Solar Space 630Wp SS8-72HD
The Solar Space 630Wp SSA-66 HD is a high-performance solar panel designed for maximum performance and a sleek aesthetic. The panels generate more energy, even in less-than-ideal lighting conditions such as cloudy or low irradiance.
Overview
Model: SSA-66HD 630 Wp (Silver/white frame, n-type TOPCon, bifacial glass-glass)
Type: Monocrystalline solar panel with bifacial operation — that is, the panel can convert sunlight from both sides into electricity.
Ideal for: Roof and ground mounting on residential or commercial installations where maximum output and long life are desired.
Technical specifications
| Feature | Value / Property |
|---|---|
| Nominal power (Pmax) | 630 Wp |
| Number of cells | 144 cells |
| Cell type | N-type TOPCon — advanced cell technology with low degradation and high efficiency. |
| Module efficiency (STC) | 22.84% |
| Power tolerance | 0% to +3% — guaranteed minimum 590 Wp or slightly more. |
| Temperature coefficient Pmax | –0.29 %/°C |
| Max. system voltage | 1500 V — suitable for large-scale installations. |
| Shape / Construction | Glass–glass (glass/glass) module — robust design provides extra durability. |
| Frame / Backsheet color | Silver/white — neutral look, suits many installations. |
| Dimensions (H x W x D) | 2278 × 1134 × 30 mm |
| Weight | 31.2 kg |
| Connector / cable | Stäubli MC4-EVO2, cable ± 1200 mm (+ / –) |
| Mechanical load capacity | Snow load up to 5400 Pa , wind load up to 2400 Pa — suitable for severe weather conditions. |
| Product warranty | 15 years |
| Performance guarantee | 30 years — 87% of nominal power (after 30 years) guaranteed. |
Key Benefits
High yield per m² thanks to the high peak power (590 Wp) and high efficiency (22.84%). Ideal for generating significant power on small roof surfaces.
Long life & reliability N-type TOPCon cells combine low degradation with good performance, and the glass-glass construction and sturdy frame make the panel resistant to harsh environments.
Bifacial design allows for additional yield through reflected light (e.g. light soil, roofing, snow), which can increase the total energy yield per panel.
Compatible with large-scale installations due to high system voltage (up to 1500 V) and modern connector (MC4-EVO2).
Less performance loss in hot weather - relatively low temperature coefficient, which means the panel remains more efficient in warm weather.
